Volume of a Cylinder: Formula, Examples & Conversion Guide
Anyone who’s ever tried to figure out how much liquid a cylindrical tank holds has bumped into the same question: is it radius or diameter? The basic formula is V = πr²h, where r is the radius of the circular base and h is the height (BYJU’s (Indian ed-tech platform)), and with the right conversions, that simple equation lets you calculate capacity in litres or cubic metres.
Formula: V = πr²h ·
Pi (π): 3.141592653589793 ·
1 m³ in litres: 1000 ·
1 litre in cm³: 1000 ·
Common shapes: Right circular cylinder
Quick snapshot
- Measure radius or diameter (The Knowledge Academy (professional training provider))
- Measure height (The Knowledge Academy) (The Knowledge Academy (professional training provider))
- Plug into formula: V = πr²h (BYJU’s) (The Knowledge Academy (professional training provider))
- Compute volume in chosen units (Vedantu) (The Knowledge Academy (professional training provider))
- m³ to litres: multiply by 1000 (Vedantu)
- litres to m³: divide by 1000 (Vedantu)
- cubic inches to litres: multiply by 0.016387 (The Knowledge Academy)
- Cylinder: radius 3 cm, height 5 cm → 141.37 cm³ (0.141 L) — based on formula from BYJU’s
- Cylinder: radius 0.5 m, height 2 m → 1.5708 m³ (1570.8 L) — based on formula from BYJU’s
Five essential facts, one reference: the constants and units you’ll need to apply the formula correctly.
| Label | Value |
|---|---|
| Formula | V = πr²h (BYJU’s) |
| Common units | cubic meters, litres, cubic inches (Vedantu) |
| Pi value | 3.141592653589793 (Vedantu) |
| 1 m³ in litres | 1000 (Vedantu) |
| Standard cylinder shape | Right circular cylinder (BYJU’s) |
How do you find the volume of a cylinder?
Using radius and height
- Measure the radius of the circular base. If you only have the diameter, divide it by 2 (Vedantu).
- Measure the height of the cylinder.
- Substitute the values into V = πr²h. Square the radius, multiply by π, then multiply by height (The Knowledge Academy).
- Check that all units are consistent. Convert if needed before multiplying.
Example: a cylinder with radius 4 cm and height 10 cm has volume V = π × (4)² × 10 = π × 16 × 10 ≈ 502.65 cm³. That’s roughly 0.503 litres.
Using diameter and height
When you’re given the diameter instead, first find the radius: r = d/2 (Vedantu). Then apply the same formula.
Example: a fuel tank with diameter 60 cm and height 120 cm has radius 30 cm. Volume = π × (30)² × 120 = π × 900 × 120 ≈ 339,292 cm³, or 339.3 litres.
One common mistake is plugging the diameter directly into the formula. That gives four times the actual volume. Always halve the diameter first — a 10 cm diameter means 5 cm radius, not 10.
The implication: Halving the diameter first prevents a fourfold error in volume.
What is the general formula for the volume of a cylinder?
The formula: V = πr²h
The volume of a right circular cylinder is the area of its circular base multiplied by the height (Vedantu). Since the base area is πr², the final expression is V = πr²h (BYJU’s). This works for any cylinder whose sides are perpendicular to the base.
Derivation from area of circle
The base of a cylinder is a circle. Its area is πr². Stacking that area over a height h gives the volume. π is a constant approximately 3.14159 (Vedantu). The formula is valid for all right circular cylinders — from a soup can to a chemical tank.
Think of it as stacking coins: the area of one coin is πr², and stacking h identical coins fills the full volume. No other shape with the same base and height holds more — that’s the principle behind cylindrical packaging efficiency.
The pattern: The base area stacking concept explains why the formula works for any right circular cylinder.
How to calculate cylinder capacity in litres?
Converting cubic meters to litres
1 cubic metre equals 1000 litres (Vedantu). So once you have the volume in m³, multiply by 1000 to get litres. For example, a cylinder with volume 2.5 m³ holds 2500 litres.
Converting cubic inches to litres
1 litre equals about 61.02 cubic inches, or alternatively 1 cubic inch equals 0.016387 litres (The Knowledge Academy). Multiply your volume in cubic inches by 0.016387 to get litres. For instance, a 1000 in³ cylinder holds about 16.4 litres.
The pattern: volume in litres = volume in m³ × 1000; volume in litres = volume in cm³ ÷ 1000 (Vedantu).
How to calculate m³ for cylinder?
Using radius in meters
To get volume directly in cubic metres, measure both radius and height in meters, then apply V = πr²h. Example: a water tower with radius 1.5 m and height 4 m has volume = π × (1.5)² × 4 = π × 2.25 × 4 ≈ 28.27 m³.
Using diameter in meters
If your diameter is 3 meters, the radius is 1.5 m. Continue with the same formula. Always convert diameter to radius before squaring.
What this means: using meters keeps the unit stream simple — the answer is already in the standard SI unit for large volumes, making it easy to switch to litres or gallons.
How to calculate how much liquid a cylinder can hold?
Determining fill level
The maximum liquid volume equals the total cylinder volume. For a partial fill, use the height of the liquid column instead of the full height in the formula (The Knowledge Academy). So if a cylindrical tank is only half full, the volume held is V = πr²h_liq with h_liq as the liquid height.
Accounting for wall thickness
For a pipe or a vessel with thick walls, the internal volume depends on the inner radius, not the outer. Measure the inner diameter directly, or subtract wall thickness from the outer radius to find the true capacity.
The trade-off: if you ignore wall thickness, you overestimate capacity by the volume of the wall itself — a small effect for thin-walled containers but significant for high-pressure tanks.
“The volume of a cylinder is the area of the circular cross-section multiplied by the height.”
“Volume of a cylinder equals the area of the base multiplied by the height of the cylinder.”
For anyone sizing a cylindrical tank or pipe, the implication is clear: always start with the inner radius and consistent units, or you’ll face a miscalculation that could scale up to thousands of litres. A 1 cm error in radius on a 1 m³ tank shifts the volume by over 30 litres — a costly mistake in any real-world application.
vedantu.com, omnicalculator.com, youtube.com, youtube.com, youtube.com
For a more detailed breakdown of the formula and its applications, refer to the cylinder volume formula guide which includes worked examples and unit conversions.
Frequently asked questions
What is the volume of a cylinder with radius 5 cm and height 10 cm?
Volume = π × (5)² × 10 = π × 25 × 10 ≈ 785.4 cm³, which is 0.7854 litres.
How do I calculate the volume of a cylinder if I only know the circumference?
Use circumference C to find radius: r = C/(2π). Then apply V = πr²h.
What is the difference between volume and capacity?
Volume is the total space occupied, measured in cubic units. Capacity is the maximum fluid the cylinder can hold, often expressed in litres or gallons. They are numerically equal for a rigid container.
How to calculate the volume of a half cylinder?
Calculate the full cylinder volume, then divide by 2. For a horizontal cylinder half-filled, use the formula for partial fill — it’s more complex because the cross-section is not a rectangle.
What is the volume of a cylinder in US gallons?
First calculate volume in litres, then divide by 3.785 to get US gallons (The Knowledge Academy). For UK gallons, divide by 4.546.
How does wall thickness affect the internal volume of a cylinder?
The internal volume uses the inner radius. Subtract the wall thickness from the outer radius to find the true inner radius. For thin-walled containers (<1% of radius), the difference is negligible; for thick pressure vessels, it can reduce capacity by 5–15%.
Can I use the same formula for an elliptical cylinder?
No. For an elliptical cylinder, the base area is π × a × b (where a and b are the semi-axes). The volume becomes V = π a b h. It’s a different shape; the standard formula only applies to circles.
For anyone working with cylindrical tanks, the choice between using radius or diameter is clear: always start with the radius, or you’ll overestimate volume by a factor of four. In practice, that means double-checking every measurement before trusting the result for procurement, design, or chemical dosing. 4 to the Power of 3 – Equals 64, Step-by-Step Explained and 30 C to F: 86°F Exact Conversion Chart & Guide.
